Description:
Model: CYS-S0250
Item Name: 25Kg Digital waterproof servo
Size: 40.5*20*38MM
Torque: 22Kg.cm ~ 25Kg.cm
Speed: 0.14sec ~ 0.12sec/60 degree
Weight: 62± 1 g
Control System: (+)Pulse Width Control 1500usec Neutral
Operating Voltage: 6.0~7.4Volts
Operating Temperature Range: (-)10 to +50 degree C
Operating Speed (6.0V): 0.14sec/60° at no load
Operating Speed (7.4V): 0.12sec/60° at no load
Stall Torque (6.0V): 22kg.cm
Stall Torque (7.4V): 25kg.cm
Operating Angle: 45deg.one side pulse traveling 500 usec
Direction: Anticlockwise/Pulse Traveling 1000~2000usec
Current Drain (6.0V): 20mA/idle and 100mA no load operating
Current Drain (7.4V): 20mA/idle and 150mA no load operating
Stall Current: 2.5A/2.8A
Dead Band Width: 4usec
Motor Type: NdFeB
Bearing Type: Dual ball bearing
Horn gear spline: 25T
Gear Type: Metal
Connector Wire Length: 300mm±5mm
Wire info
Brown/Black = Negative
Red = Positive
Orange/White = Signal
Package Included:
1x CYS-S0250 25kg Supersonic Waterproof Metal Digital Servo
